SkyRC B6 AC Neo Simple Cargador

Specifications

Size and Weight

Shell material: PC-ABS V0

Size: 70.6*50.6*46mm

Weight: 150g

Display

Display Type: TN

Size: 1.77 inch

Panel Active Area: 28.03*35.04mm

Resolution: 128x160 Pixel

Number of Colors: 262K

Power

AC Input Voltage: 100V～240V 50/60Hz

DC Input Voltage: 10-30.0V

Charger power:

DC：200W

AC：60W

QC3.0 / PD: 5V⎓3A, 9V⎓3A, 12V⎓3A, 20V⎓3.25A Max. 65W

Discharge power:

19W based on 6S(4.2V/S)

Battery

Battery Types/Cells:

LiPo/LiFe/LiIon/LiHV: 1-6cells

NiMH/NiCd: 1-15cells

Pb: 3S/6S

Charge and Discharge

Charge current

LiPo/LiFe/LiIon/LiHV/NiMH/NiCd/Pb：0.2-10.0A

Discharge current

LiPo/LiFe/LiIon/LiHV/NiMH/NiCd/Pb：0.1-2.0A

Balance current

LiPo/LiFe/LiIon/LiHV: Max. 500mA

Operation

LiPo/LiFe/LiIon/LiHV: Balance CHG, Charge, Storage, Discharge

NiMH/NiCd: Charge, Re-Peak, CYCLE_C_D, CYCLE_D_C, Dishcarge

Pb: Normal, AGM Charge, Cold Charge, Discharge
